Installed Base

HOMEInstalled Base

BERARD - materielsPRODUCTION

3D Laser
1 laser cutting unit and CO² Trumpf TLC1005 3D laser welding
Press lines
3 automatic press cutting lines with feed and straightener – 120 to 250 tonnes
7 manual presses of 30 to 250 tonnes.
Cutting applications
3 Trumpf L5030 laser cutting units
1 Trumpf TC6000 combined laser / mechanical drill
Folding
9 Trumpf and Amada press brakes of 25 to 130 tonnes, up to 3 meters
Finishing
2 MIG welding robots / 2 work tables (2400 * 1700 mm and 2000 * 1000 mm)
8 semi-automatic or TIG pulse welding stations
6 electric spot welders
3 crimping presses, 1 radial riveting machine
1 1500*8 mm max. leveling machine

IT

CAD/CAM : Cocreate program associated with the leading CAD/CAM software packages.
All machinery connected by intranet to workstations for loading programs.
CAPM system: data management system on a network, with 45 workstations and 4 data servers.
OCTAL V11 ERP: Management of customer orders and follow-up of entire manufacturing process, whether JIT or batch approach.

INSPECTIONS

4 people in the Quality department
3 measurement columns
1 Romer Omega 2025 measuring arm, with G-Surf software
1 Duromaster 200 RB hardness tester
